Auto Cine
- Introduced
- 1928
- Original archive
- View preserved page ↗
2 photographs — swipe, or tap to enlarge
Specifications and history Jacques Bogopolsky's Auto Cine projector for 16mm and 9.5mm film
At a glance
- Overall Dimensions
- Approximately 12in x 8in x 5in (30cm x 20cm x 12cm)
- Weight
- Approximately 10 lbs (4.5 kg)
- Construction
- Black "crinkle" paint finish.
- Reel Capacity
- Reel arms accommodate 400 ft reels.
- Power
- 145 volt AC mains lead
- Lamp
- Osram Nitra 6V 20W with integrated mirror.
- Lens
- Hermagis Paris F 45mm
- Speed
- 16 frames per second; Stop; Rewind
- Other Features
- Adjustable base allows for the proper alignment of the projected image.
Specifications in detail
- Threading
- Manual threading and loop forming of film; Interchangeable sprockets and guides allow projection of either 16mm or 9.5mm film.
